Specifications:

• Warranty: 1 Years
• Package Quantity: 1

Connector(s):

• Connector A:
  • 1 – USB 2.0 Type-A (4 pin, 480Mbps)
• Connector B:
  • 1 – DB-9 (9 pin, D-Sub)

Environmental:

• Operating Temperature: 0C to 60C (32F to 140F)
• Storage Temperature: -20C to 80C (-4F to 176F)
• Humidity: 0~65% RH

Hardware:

• Ports: 1
• Interface: Serial
• Bus Type: USB 2.0
• Port Style: Cable Adapters
• Industry Standards:
  • USB 1.1/2.0
  • RS232
• Chipset ID: Prolific – PL2303GT

Packaging Information:

• Shipping Weight: 2.1 oz (60.0 g)
• Package Dimensions:
  • Height: 0.8 in (2.1 cm)
  • Length: 5.4 in (13.8 cm)
  • Width: 7.8 in (19.8 cm)

Performance:

• Serial Protocol: RS-232
• Max Baud Rate: 921.6 Kbps
• Data Bits: 5, 6, 7, 8
• FIFO: 512 Bytes
• Flow Control: None, Xon/Xoff, RTS/CTS, DTR/DSR
• Parity: Odd, Even, Mark, Space, or None Parity Modes
• Stop Bits: 1, 1.5, 2
• MTBF: 30,000 Hours

Physical Characteristics:

• Color: Silver & Blue
• Product Dimensions:
  • Height: 0.8 in (2.0 cm)
  • Length: 16.9 in (43.0 cm)
  • Width: 1.4 in (3.4 cm)
• Weight of Product: 1.4 oz (40.0 g)
• Material: Plastic
• Cable Length: 16.9 in (43 cm)

Software Compatibility:

• OS Compatibility:
  • Windows Vista, 7, 8, 8.1, 10, 11
  • Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016, 2019, 2022
  • macOS 9.x, 8.x, 10.6 to 10.15, 11.0, 12.0, 13.0, 14.0, 15.0
  • Linux 2.4.31 and up – LTS Versions only
• Microsoft WHQL Certified: Yes

Special Notes / Requirements:

• System and Cable Requirements: One available USB 1.1 (or above) port

What’s in the Box:

• 1 – USB to RS232 Adapter
• 1 – Instruction Manual
